CS 230
- Dust free when used with SPE 316 vacuum
- Cuts with 1 or 2 blades which are adjustable
- Spacing between blades
- Compact and easily tansported
- Available in petrol/gasoline and electric
SKU: CS 230
Category: Saws
CS 230
- Dust free when used with SPE 316 vacuum
- Cuts with 1 or 2 blades which are adjustable
- Spacing between blades
- Compact and easily tansported
- Available in petrol/gasoline and electric

Product Description
SPE Floor saws are simple and safe to operate, portable, and durable. From being manufactured throughout with high grade materials to a high engineering quality, a long service life is guaranteed.
A specialist saw developed to cut with smaller blades for joint cutting and chasing. The machine can be fitted with either one or two number diamond blades. Spacers are available to put up to a 40mm (1.6”) space between two blades. The blade
guard is articulated and fully floating. This ensures the process is dust free, even when raising/lowering in and out of the cut.
Technical Specs
Type | CS 450 | |||
---|---|---|---|---|
Part Number | CS 230-1 | CS 230-2 | CS 230-3 | CS 230-4 |
Blade Guard Capacity | 230mm (9.1") | 230mm (9.1") | 230mm (9.1") | 230mm (9.1") |
Depth of Cut | 55mm (2.2") | 55mm (2.2") | 55mm (2.2") | 55mm (2.2") |
Blade Shaft Diameter | 22.2mm (0.9") | 22.2mm (0.9") | 22.2mm (0.9") | 22.2mm (0.9") |
Blade Shaft Speed | 2500rpm | 2500rpm | 5000rpm | 5000rpm |
Engine/Motor Power | 3hp/2.2kW | 3hp/2.2kW | 5.5hp/4.1kW | 5.5hp/4.1kW |
Engine/Motor Speed | 1400rpm | 1400rpm | 2800rpm | 3000rpm |
Machine Dimensions | ||||
Length | 1160mm (45.7") | 1160mm (45.7") | 1160mm (45.7") | 1160mm (45.7") |
Width | 600mm (23.6") | 600mm (23.6") | 600mm (23.6") | 600mm (23.6") |
Height | 800mm (31.5") | 800mm (31.5") | 800mm (31.5") | 800mm (31.5") |
Weight | 62kg (136lbs) | 62kg (136lbs) | 62kg (136lbs) | 62kg (136lbs) |
Water Tank Capacity | - | - | - | - |
Engine/Motor type | 110V 1Phase | 230V 1Phase | 400/460V 3Phase | Petrol/Gasoline |
