Product Description
Reinforced structure, drum & opening
- The mixing blades are 3mm thick with a curved edge to avoid concrete getting stuck at the bottom of the drum.
- The blades are welded to the drum at 4 points for strength & durability.
Sturdy Frame
- Built with 3.6mm diameter tube, offering extra support and durability.
- The legs have a flattened tip to prevent sinking and slipping.
Designed for operator safety
- Engine exhaust vents to the side for better ventilation and to prevent burns.
- Emergency stop button is located on the side of the engine within sight and reach of the operator.
Technical Specifications
Model | MIX150-4 |
---|---|
Power Source | Honda GX160 Petrol Engine |
Power Output | 5,5 hp |
Mixing Production | 1,00 m3/hour |
Mixing Capacity | 90 L |
Drum Volume | 130 L |
Drum Speed | 30 rpm |
Drum Mouth Diametre | 420 mm |
Mixer Weight | 72 kg |
Stand Weight | 9 kg |
Dimensions - no stand | 1300 x 600 x 940 mm (L x W x H) |
Dimensions - with stand | 1400 x 1050 x 1425 mm (L x W x H) |
Box Dimensions - assembled | 1030 x 585 x 755 mm |
Box Dimensions - disassembled | 1300 x 600 x 940 mm |
